Adjustable Clamping Levers Inner Parts From Stainless Steel With Screw

Adjustable Clamping Levers Inner Parts From Stainless Steel With Screw
Adjustable Clamping Levers Inner Parts From Stainless Steel With Screw
Send Inquiry
Product Code : 01
Product Description

Material :

  • Lever
    • Zinc die-cast, plastic coated, orange similar to RAL 2004, matt structure
    • Zinc die-cast, plastic coated, black, similar to RAL 9005, matt structure
  • Threaded part
    • Stainless steel 1.4305
  • Inner parts
    • Stainless steel 1.4305
Specification :

Dimensions


Art.-No.

d 1

d 2

d 3

h 1

h 2

h 3

h 4

l 2

t

[mm]

[g]

ORANGE

13

M 3

10,0

24,5

 4,0

3,5

30,5

 30

 7

 26

24390.0032

13

M 4

10,0

24,5

 4,0

3,5

30,5

 30

 9

 25

24390.0036

14

M 5

10,0

24,5

 4,0

3,0

35,0

 45

 8

 33

24390.0111

14

M 6

10,0

24,5

 4,0

3,0

35,0

 45

 8

 33

24390.0121

18

M 8

13,5

31,0

 6,5

3,0

45,0

 62

10

 67

24390.0321

22

M 8

16,0

36,0

 8,0

3,5

52,0

 74

14

112

24390.0411

22

M10

16,0

36,0

 8,0

3,5

52,0

 74

14

109

24390.0421

25

M10

19,0

43,0

11,0

4,0

63,0

 89

17

175

24390.0511

25

M12

19,0

43,0

11,0

4,0

63,0

 89

17

171

24390.0521

30

M12

23,0

50,5

12,0

5,0

76,0

108

22

286

24390.0611

30

M16

23,0

50,5

12,0

5,0

76,0

108

22

269

24390.0621

BLACK

13

M 3

10,0

24,5

 4,0

3,5

30,5

 30

 7

 26

24390.0034

13

M 4

10,0

24,5

 4,0

3,5

30,5

 30

 9

 25

24390.0038

14

M 5

10,0

24,5

 4,0

3,0

35,0

 45

 8

 33

24390.0114

14

M 6

10,0

24,5

 4,0

3,0

35,0

 45

 8

 33

24390.0124

18

M 8

13,5

31,0

 6,5

3,0

45,0

 62

10

 67

24390.0324

22

M 8

16,0

36,0

 8,0

3,5

52,0

 74

14

112

24390.0414

22

M10

16,0

36,0

 8,0

3,5

52,0

 74

14

109

24390.0424

25

M10

19,0

43,0

11,0

4,0

63,0

 89

17

175

24390.0514

25

M12

19,0

43,0

11,0

4,0

63,0

 89

17

171

24390.0524

30

M12

23,0

50,5

12,0

5,0

76,0

108

22

286

24390.0614

30

M16

23,0

50,5

12,0

5,0

76,0

108

22

269

24390.0624
