Ball Casters With Sheet Steel Housing

Ball Casters With Sheet Steel Housing Specification

Type
Ball Casters With Sheet Steel Housing

Material
Sheet Steel Housing, Steel Ball

Application
Furniture, trolleys, equipment, office chairs, light industrial use

Rolling Resistance
Smooth and easy movement on hard and soft surfaces

Noise Level
Low

Mounting Type
Side plate or bottom mounting, bolt fitting

Housing Finish
Zinc-plated or chrome-plated

Ball Diameter
16 mm to 50 mm (varies by model)

Temperature Range
-20C to +60C

Load Capacity
Up to 30 kg per caster

Swivel Rotation
360 degrees

Ball Casters With Sheet Steel Housing Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
2000 Pieces Per Month

Delivery Time
2-3 Days

About Ball Casters With Sheet Steel Housing

Material :

Cap

Steel, galvanized
Stainless steel

Housing

Steel, galvanized
Stainless steel

Ball

Ball-bearing steel
Stainless steel

Specification :

Dimensions [mm]							Carrying figure C [N]	Location hole D 1 1)[mm]	[g]	Art.-No.
d 1	Ball	d 2	h 1	h 2	h 3	h 4	Carrying figure C [N]	Location hole D 1 1)[mm]	[g]	Art.-No.
Cap And Housing Zinc- Coated
12,6 +0,055	8	17	4,8 +0,15	11,2	1,8	3,2	100	12,57 +0,03	7	22750.0000 2)
18,0 +0,055	12	23	7,4 +0,15	15,5	2,0	4,3	250	17,97 +0,03	18	22750.0002 2)
24,0 +0,065	15	31	9,5 +0,20	21,5	2,5	6,1	500	23,95 +0,05	40	22750.0004 2)
36,0 +0,080	22	45	9,8 +0,20	29,5	2,9	5,7	1300	35,90 +0,05	134	22750.0008
45,0 +0,080	30	55	13,8 +0,30	37,5	3,7	7,9	2500	44,85 +0,05	277	22750.0012
62,0 +0,095	45	75	19,0 +0,40	53,7	4,2	10,3	6000	61,83 +0,07	741	22750.0016
All Parts Zinc-Coated, Ball From Stainless Steel
12,6 +0,055	8	17	4,8 +0,15	11,2	1,8	3,2	70	12,57 +0,03	7	22750.0020 2)
18,0 +0,055	12	23	7,4 +0,15	15,5	2,0	4,3	180	17,97 +0,03	18	22750.0022 2)
24,0 +0,065	15	31	9,5 +0,20	21,5	2,5	6,1	370	23,95 +0,05	40	22750.0024 2)
36,0 +0,080	22	45	9,8 +0,20	29,5	2,9	5,7	970	35,90 +0,05	132	22750.0028
45,0 +0,080	30	55	13,8 +0,30	37,5	3,7	7,9	1900	44,85 +0,05	273	22750.0032
62,0 +0,095	45	75	19,0 +0,40	53,7	4,2	10,3	4500	61,83 +0,07	739	22750.0036
All Parts From Stainless Steel
12,6 +0,055	8	17	4,8 +0,15	11,2	1,8	3,2	70	12,57 +0,03	7	22750.0040 2)
18,0 +0,055	12	23	7,4 +0,15	15,5	2,0	4,3	180	17,97 +0,03	18	22750.0042 2)
24,0 +0,065	15	31	9,5 +0,20	21,5	2,5	6,1	370	23,95 +0,05	39	22750.0044 2)
36,0 +0,080	22	45	9,8 +0,20	29,5	2,9	5,7	970	35,90 +0,05	133	22750.0048
45,0 +0,080	30	55	13,8 +0,30	37,5	3,7	7,9	1900	44,85 +0,05	272	22750.0052
1) Reference Value For 2 Mm Sheet Steel/ 5 mm Aluminium (force Fit)
2) Without Felt Seal

Robust Construction for Reliable Performance

The sheet steel housing and steel ball construction of these ball casters guarantee strength and longevity. Zinc-plated or chrome-plated finishes provide corrosion resistance, maintaining both functionality and aesthetic appeal even in demanding environments.

Flexible Mounting and Application Options

Choose from side plate or bottom bolt mounting to suit your installation requirements. These ball casters are adaptable for furniture, office chairs, equipment, and trolleys, making them a go-to solution for a variety of residential, commercial, and industrial uses.

Smooth, Silent Mobility for Every Surface

Enjoy low rolling resistance and minimal noise, allowing easy and unobtrusive movement on hard or soft floors. Their 360-degree swivel design ensures effortless navigation and precise control, enhancing practicality in any setting.

FAQs of Ball Casters With Sheet Steel Housing:

Q: How do I select the right ball caster size for my application?

A: Choose a ball diameter between 16 mm and 50 mm based on the weight, stability, and space requirements of your furniture or equipment. Ensure that the load per caster does not exceed 30 kg for optimal safety and performance.

Q: What surfaces are suitable for these ball casters?

A: These ball casters are engineered for smooth operation on both hard and soft surfaces, including wood, tile, carpet, and laminated flooring, making them versatile for diverse settings such as homes, offices, and industrial spaces.

Q: When should I use side plate versus bottom mounting?

A: Select side plate mounting when you need to attach the caster to the side of a panel or frame. Bottom mounting or bolt fitting is ideal for fixing casters to the underside of furniture or trolleys, delivering a secure and stable installation.

Q: Where can these casters be installed?

A: They are ideal for a broad range of installations, including office chairs, furniture units, rolling trolleys, equipment stands, and other mobile fixtures used in residential, institutional, or light industrial locations.

Q: What is the process for installing these ball casters?

A: First, select the appropriate mounting typeside plate or bottom bolt. Position the caster as required, align the mounting holes, and secure using suitable bolts or screws. Ensure all fastenings are tight to achieve stable and reliable movement.

Q: How do these casters benefit my furniture or equipment?

A: These casters enhance mobility, reduce floor damage, and provide quiet, smooth rolling. Their robust construction and attractive finish also contribute to equipment durability and a polished look.
