Star Grips DIN 6336 Cast Iron

Star Grips DIN 6336 Cast Iron Specification

Type
Star Grips

Material
Cast Iron

Application
Industrial machinery, clamping operations

Temperature Resistance
Up to 250C

Corrosion Resistance
Yes, with surface treatment

Finish
Black Powder Coated

Shape
Star-shaped

Mounting Type
Internal thread

Grip Diameter
60 mm to 125 mm

Thread Size
Available in various metric sizes (M6, M8, M10, M12, etc.)

Standard
DIN 6336

Weight
Depends on diameter and thread size

Star Grips DIN 6336 Cast Iron Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
2000 Pieces Per Month

Delivery Time
2-3 Days

About Star Grips DIN 6336 Cast Iron

Sandblasted or tumbled.

Material :

Handle

Grey cast iron GG 20, bright

Specification :

Dimensions [mm]											[g]	Art.-No.
d 1	d 2	d 4 H7	d 5	d 6	h 1	h 2	h 3	t 1	t 2	t 4	[g]	Art.-No.
Raw Part, Form A -picture1
32	12	-	-	-	21	-	10	-	-	-	38	24620.0032
40	14	-	-	-	26	-	14	-	-	-	69	24620.0040
50	18	-	-	-	34	-	20	-	-	-	115	24620.0050
63	20	-	-	-	42	-	25	-	-	-	228	24620.0063
80	25	-	-	-	52	-	30	-	-	-	415	24620.0080
100	32	-	-	-	65	-	38	-	-	-	855	24620.0090
With Smooth Throughgoing Bore, Form B -Picture2
32	12	6	-	-	-	20	-	-	-	-	34	24620.0132
40	14	8	-	-	-	25	-	-	-	-	59	24620.0140
50	18	10	-	-	-	32	-	-	-	-	95	24620.0150
63	20	12	-	-	-	40	-	-	-	-	171	24620.0163
80	25	16	-	-	-	50	-	-	-	-	338	24620.0180
100	32	20	-	-	-	63	-	-	-	-	709	24620.0190
With Smooth Blind Hole, Form C -Picture3
32	12	6	-	-	-	20	-	15	12	-	36	24620.0232
40	14	8	-	-	-	25	-	18	15	-	61	24620.0240
50	18	10	-	-	-	32	-	21	18	-	99	24620.0250
63	20	12	-	-	-	40	-	25	22	-	200	24620.0263
80	25	16	-	-	-	50	-	32	28	-	380	24620.0280
100	32	20	-	-	-	63	-	40	36	-	706	24620.0290
With Thread, Drilled Out, Form D -Picture4
32	12	-	M6	6,4	-	20	-	-	-	10	34	24620.0332
40	14	-	M8	8,4	-	25	-	-	-	12	60	24620.0340
50	18	-	M10	10,5	-	32	-	-	-	16	95	24620.0350
63	20	-	M12	13,0	-	40	-	-	-	20	191	24620.0363
80	25	-	M16	17,0	-	50	-	-	-	30	339	24620.0380
100	32	-	M20	21,0	-	63	-	-	-	38	704	24620.0390
With Threaded Blind Hole, Form E -Picture5
32	12	-	M6	-	-	20	-	-	12	-	35	24620.0432
40	14	-	M8	-	-	25	-	-	15	-	63	24620.0440
50	18	-	M10	-	-	32	-	-	18	-	103	24620.0450
63	20	-	M12	-	-	40	-	-	22	-	205	24620.0463
80	25	-	M16	-	-	50	-	-	28	-	359	24620.0480
100	32	-	M20	-	-	63	-	-	36	-	730	24620.0490

Engineered for Demanding Applications

Star Grips DIN 6336 are expertly engineered for industrial tasks, providing reliable clamping and adjustment functions. The star-shaped design enables easy handling and optimal grip, making them a preferred choice for operators working with machinery in settings such as factories, workshops, and heavy-duty plants.

Superior Material and Finish

Crafted from premium cast iron and finished with a high-quality black powder coat, these grips ensure strength and longevity. The special surface treatment enhances their resistance to corrosion, allowing for consistent performance in both dry and humid environments.

Versatile Specifications

With thread sizes available from M6 to M12 and grip diameters spanning 60 mm to 125 mm, these star grips cater to a variety of machine requirements. The internal thread mounting allows for straightforward installation, supporting diverse clamping and fastening processes.

FAQs of Star Grips DIN 6336 Cast Iron:

Q: How are Star Grips DIN 6336 installed on machinery?

A: Star Grips DIN 6336 are mounted using an internal thread, which fits securely onto compatible bolts or stems of industrial machines. Installation is typically straightforward, requiring minimal tools.

Q: What are the key benefits of using these cast iron star grips?

A: These star grips offer strong handling, high durability, resistance to elevated temperatures (up to 250C), and corrosion resistance due to their surface treatment. Their robust cast iron construction ensures longevity in demanding industrial settings.

Q: When should I choose cast iron star grips over other materials?

A: Cast iron star grips are ideal when strength, heat resistance, and durability are crucial. They are suited for environments where high mechanical loads and elevated temperatures are expected, making them suitable for heavy-duty clamping operations.

Q: Where are Star Grips DIN 6336 commonly used?

A: They are widely used in industrial machinery, manufacturing plants, and clamping operations where manual adjustment or securing of machine parts is necessary. Their use is prevalent across factories, workshops, and maintenance facilities.

Q: What process ensures the corrosion resistance of these grips?

A: A specialized surface treatment combined with black powder coating is applied to the grips, which significantly enhances their resistance to corrosion in both dry and moist industrial conditions.

Q: How does the grip diameter affect application suitability?

A: Larger grip diameters (up to 125 mm) provide better leverage and control for heavy-duty clamping tasks, while smaller diameters accommodate more compact or precision applications. Selecting the appropriate diameter ensures ergonomic efficiency and safe operation.
